Pneumatic Primer for automated priming of chips
The pneumatic priming device is recommended for automated priming of the co-culture SynVivo chips. This method is much simpler and more robust than the manual method which requires water immersion in a vacuum desiccator. Protocols for using SynVivo chips makes use of this pneumatic priming device to impart a constant low pressure on the fluid to prime the microfluidic device.
Click to watch video showing the pneumatic priming device in action
SynVivo Catalog#: 205001
The SynVivo® Cell Impedance Analyzer is designed to measure changes in impedance (resistance) across cells cultured in SynVivo IMN2-Z devices. The SynVivo® Cell Impedance Analyzer provides real-time monitoring of cellular changes at frequency of 500, 1,000, and 10,000 Hz.
Perfect for non-invasive and label free monitoring of tight junction formation between cells, the system offers robust and easy protocols for error free operations. It comes standard with power adapter and micro grabbers for use with SynVivo IMN2-Z devices.
SynVivo Catalog#: 304001
We are proud to offer select Harvard Apparatus syringe pumps for use with SynVivo biochips. These high quality pumps have been extensively tested and offer a feature rich solution at an affordable price.
Standard Infuse/Withdraw Pump 11 Elite Programmable
The Pump 11 Elite Series of syringe pumps expands its capabilities to satisfy your experimental requirements. These compact syringe pumps carry on the tradition as the premiere workhorse infusion pump, offering unparalleled ease of use with a high resolution touch screen with intuitive icon interface. The Pump 11 Elite Series allows you to create, save and run simple to complex methods without a PC.
These syringe pumps have a new mechanism that includes a tight gripping, more secure syringe clamp for syringes ranging from 0.5µl to 60ml (single syringe) and 0.5µl to 10 ml (dual syringe). The Pump 11 Elite Series offers enhanced flow performance with high accuracy and smooth flow from 1.28 pl/min to 88.28 ml/min.
The Pump 11 Elite Series is available in Infusion Only or Infusion/Withdrawal Programmable Models with single or dual syringe racks. These pumps have advanced connectivity with a USB serial port for computer control, RS-485 (or optional RJ-ll) ports for daisy chaining pumps and Digital I/O for remote control.
SynVivo Catalog#: 301001
Remote Infuse/Withdraw Pump 11 Elite Nanomite Programmable
The Pump 11 Elite Nanomite is a single syringe infusion/withdrawal programmable syringe pump with a flow rate range of 3.66 pl/min to 3.818 ml/min with 11 lbs of adjustable force across the entire flow rate range. It can accommodate syringes from 0.5 µl to 1 ml.
The Pump 11 Elite Nanomite Syringe Pump is very easy to use with an LCD color touch screen and icon interface. This pump allows you to create, save and run simple to complex Methods without a PC. The Method profiles available on this pump are Constant Rate, Ramp, Gradient (binary) and Autofill. Delays can be set using the relative time clock.
The Message Area of the touch screen is used to display helpful instructions for the currently displayed screen. It is also used to display error or warning messages to indicate problem conditions in a Method or error conditions during pump operation. The Run Screen shows all of the pump parameters on one screen for easy review.
SynVivo Catalog#: 301002
Standard Infuse/Withdraw PHD ULTRA™ Syringe Pumps
The PHD ULTRA™ is the solution for your most demanding fluidics applications. This pump represents the latest technology in syringe pumps and was developed utilizing the feedback of the world’s largest populations of syringe pump users.
The PHD ULTRA™ will change the way you think about syringe pumps. There are three major areas which make the PHD ULTRA™ the new standard for syringe pumps.
SynVivo Catalog#: 301003
PHD ULTRA™ 6×10 MultiRack
The 6/10 multi-rack will hold up to 10 syringes from 0.5 µl to 20 ml and up to 6 syringes from 30 ml to 60 ml
SynVivo Catalog#: 301004
Pump 33 DDS (Dual Drive System) Syringe Pump
The Harvard Apparatus Pump 33 DDS (Dual Drive System) is a leap forward in syringe pump capability. The Pump 33 DDS has two independent pumping channels controlled by an intuitive touch screen interface.
This multi-purpose syringe pump employs advanced syringe mechanisms that include a tight gripping, extremely secure syringe clamp that accommodates syringe sizes 0.5 µl to 60 ml. The Pump 33 DDS offers enhanced flow performance with high accuracy and smooth flow from 1.02 pl/min to 106 ml/min.
SynVivo Catalog#: 301014
