Growth of human lymphocytes in Petri dishes placed inside incubator connected to a 2-channel temperature and CO2 controllers.
The pictures taken before and after 60 hours (2.5 days) incubation show cells growing to cover the whole bottom of the Petri dish.
Provided by Rui Liu from Kun Zhang lab, UCSD La Jolla, CA
Miniature Incubator with heated glass bottom for motorized and
type K stages, TC-MWPHB
For open bottom incubators go to TC-MWP
Designed for long-term live cell imaging and time-lapsed microscopy. For use with standard multi-well plates. Fits all brands of motorized
stages (see table below).
Incorporates heated bottom, luer-lock port for gas mixture (to control CO2
and hypoxia),
and heated cover lid (purchased separately) to prevent condensation. Built-in multiple ports for
tubing and accessories (tubing, probes and sensors).
The bottom is closed with 1mm glass (for open bottom incubator, to access with immersion objective -
consider TC-MWP model).
Consider a modified incubator for easy positioning of tubing to
deliver media and test solutions to custom devices. Click on image for inside view.
Miniature Incubator with heated bottom, TC-MWP-6
The metal heated bottom of this incubator has round cutouts, so there is no obstruction on the way of optical path
(x6 for 6-well plates, different number and pattern of cutouts can be made for different plates).
Designed for long-term live cell imaging and time-lapsed microscopy. For use with standard multi-well plates. Fits all brands of motorized
stages (see table below).
Incorporates luer-lock port for gas mixture (to control CO2
and hypoxia),
and heated cover (purchased separately) to prevent condensation. Built-in multiple ports for
tubing and accessories (probes and sensors).
The bottom thickness is 2mm, the aperture diameter is 30mm (for
6-well plates).
Recommended for long distance optics because wider microscope objectives might
not fit inside the cutouts.
For open bottom incubator, to access with immersion objective -
consider TC-MWP model.
Consider a modified incubator TC-MIW for easy positioning of tubing to
deliver media and test solutions to custom devices.
Brand |
extension (if required) |
Ludl, Prior, ASI, Marhauser,
Zeiss |
no extension required |
Nikon 236x155mm: |
TC-MI-NIK |
Thorlabs 170x130mm: |
TC-MI-THOR |
Ludl Bioprecision II, 172x116mm: |
TC-MI-LUDL |
Specifications: |
Outside dimensions: | Fits
160x110mm cutout of motorized stages; the base height is
10mm; the bottom is recessed 7mm below the mounting
surface; comes with 3mm spacers to
reduce this recessed profile to 5mm; can be leveled by set screws positioned in the corners of the incubator base |
Heated bottom: |
1mm glass for TC-MWPHB, 2mm for TC-MWP-6 |
Optical aperture and
clearance: |
112x72mm
window on the bottom;
33mm from sample to top surface; 23mm for low-profile
option (17mm inside
clearance); optional spacers allow to elevate the top surface 9.5mm - to provide more space inside the incubator |
Stability: |
0.01°C |
Use with: |
Standard
multi-well plates, 35mm dishes, and 1x3in. glass coverglasses/slides |
Condensation free lid: |
Uses
a built-in temperature sensor to connect independently to
the second channel of temperature controllers, 81x121mm optical window |
CO2 port: |
Luer-lock connector to a source of gas mixture. |
Media exchange and perfusion: |
Multiple sealed inflow/outflow ports, an optional set of adjustable tubing holders to position inflow and outflow tubing inside sample chambers. |
Click on catalog numbers below to purchase online.
Required accessories: temperature controller,
CO2 controller.
Optional accessories: inserts (see table below).
Download PDF manual.
Download PDF catalog.
|
|
Bioscience Tools
ph: 010-6759703, fax: 010-6759703
email: chengyuan@bio-goods.com
|
PRICES AND OPTIONS |
TC-MWPHB |
|
Miniature Incubator for multi-well plates, with closed heated bottom.
|
TC-MWP-6 |
|
Miniature Incubator for multi-well plates, with closed heated metal bottom and x6 30mm cutouts.
|
TC-MWPL |
|
Lid for miniature Incubator TC-MWP, MWPHP, MIW, Low Profile
|
TC-MI-THOR |
|
Adapter for ThorLabs stages, 170x130mm
|
TC-MI-NIK |
|
Adapter for Nikon motorized stages, 236x155mm
|
TC-MI-LUDL |
|
Adapter for Ludl Bioprecision II stages, 172x115mm |
TC-I-E |
|
Spacer to elevate the cover 9.5mm
|
|
|
)
