The lever operated Force Measurement Test Stand Model TSB is an economical solution for quick-action tensile testing and compression testing of up to 100 lb of force. Constructed of rugged components, this test stand is durable enough for the factory floor, yet precise enough for laboratory environments.
Features
Loading lever can be positioned in 30º increments for ease of peration
Precision ground rack for smooth precision motion
Mountinig holes for bench mounting
Low force friction brake
Specifications
Capacity
100 lb (500 N)
Stroke
6" (152 mm) without travel stops
2.75" (69.9 mm) with travel stops
